Colour |
Maximum resolution 240 x 144 DPI |
Maximum printing width (columns) 136 |
Maximum print speed 357 cps |
Maximum print speed (draft) 312 cps |
Character pitch 10,12 cpi |
Maximum number of copies 5 copies |
Built-in barcodes Code 128 (A/B/C), Code 39, EAN13, EAN8, Interleaved 2/5, POSTNET, UPC-A, UPC-E |
Print speed NLQ: 12 cpi: 78 chars/s, 10 cpi: 65 chars/s, Draft: 12 cpi: 312 chars/s, 10 cpi: 260 chars/s, HighSpeed-Draft: 12 cpi: 357 chars/s, 10 cpi: 347 chars/s |
|
Maximum print size A3 (297 x 420 mm) |
Paper tray media types Envelopes, Labels, Roll |
Continuous paper thickness range 0.065 - 0.39 mm |
Single sheet thickness range 0.065 - 0.14 mm |
|
Product colour Black, Grey |
Buffer size 128 KB |
Sound pressure level (printing) 54 dB |
Page description languages ESC P, PPDS |
Country of origin Indonesia |
|
Standard interfaces RS-232, USB 2.0 |
|
Print head 9-pin |
Print direction Bidirectional |
Print head life 400 million characters |
Ribbon life (black, draft) 4 million characters |
Mean time between failures (MTBF) 10000 h |
|
Power consumption (typical) 33 W |
AC input voltage 220 - 240 V |
|
Operating temperature (T-T) 5 - 35 °C |
Storage temperature (T-T) 5 - 35 °C |
Operating relative humidity (H-H) 10 - 80% |
Storage relative humidity (H-H) 10 - 80% |
|
Windows operating systems supported Windows 2000, Windows 7, Windows 8, Windows 98, Windows XP |
Server operating systems supported Windows Server 2008 R2 |
Bundled software Epson Status Monitor |
|
Width 546 mm |
Depth 275 mm |
Height 164 mm |
Weight 6.6 kg |
|
Quantity per pack 1 pc(s) |
Package width 220 mm |
Package depth 640 mm |
Package height 380 mm |
Package weight 7.73 g |
|
Connectivity technology Wired |
Print technology Dot matrix |
Standard media sizes Sheet Paper (single- and multi-layer), Continuous Paper (single- and multi-layer), Labels (single- and multi-layer), Roll Paper, Envelopes |
Box contents Driver and utilities (CD), Main unit, Power cable, Ribbon, Setup guide, Software (CD), User manual (CD), Warranty document |
Needles 9 Needles |
|
Products per pallet 27 pc(s) |
Pallet gross length 120 cm |
Pallet gross width 80 cm |
Pallet gross height 2.15 m |
Products per pallet layer 3 pc(s) |
Products per pallet layer (UK) 3 pc(s) |
Products per pallet (UK) 27 pc(s) |
Pallet length (UK) 120 cm |
Pallet width (UK) 100 cm |
Pallet height (UK) 2.15 m |
Harmonized System (HS) code 84433210 |
