Switch type Managed |
Switch layer L2 |
Quality of Service (QoS) support |
Web-based management |
ARP inspection |
Configuring Location Settings (CLI) |
System event log |
MIB support |
|
Basic switching RJ-45 Ethernet ports quantity 16 |
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) |
Installed SFP modules quantity 0 |
Installed SFP+ modules quantity 0 |
Combo SFP ports quantity 4 |
Power connector AC-in jack |
|
Networking standards IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
Copper ethernet cabling technology 1000BASE-T, 100BASE-TX, 10BASE-T |
Port mirroring |
Full duplex |
Flow control support |
Link aggregation |
Broadcast storm control |
Auto MDI/MDI-X |
Spanning tree protocol |
Head-of-line (HOL) blocking |
Auto-negotiation |
VLAN support |
Number of VLANs 256 |
|
MAC address table 8000 entries |
Switching capacity 40 Gbit/s |
Forwarding rate 29.8 Mpps |
Store-and-forward |
Jumbo frames support |
Jumbo frames 10000 |
Packet buffer memory 4.1 MB |
|
DHCP features DHCP client, DHCP server |
Access Control List (ACL) |
IGMP snooping |
MAC address filtering |
Loop protection |
|
Multicast support |
|
Rack mounting |
Stackable |
Form factor 1U |
Product colour Black |
LED indicators Yes |
|
Memory type DDR3-SDRAM |
Internal memory 128 MB |
Flash memory 32 MB |
Noise level 0 dB |
Mean time between failures (MTBF) 1087100 h |
|
Power source AC |
Power supply included |
AC input voltage 100 - 240 V |
AC input frequency 50/60 Hz |
Power consumption (max) 13.08 W |
|
Power over Ethernet (PoE) |
|
Operating temperature (T-T) -5 - 50 °C |
Storage temperature (T-T) -20 - 70 °C |
Operating relative humidity (H-H) 0 - 95% |
Storage relative humidity (H-H) 0 - 95% |
Heat dissipation 44.62 BTU/h |
|
Width 280 mm |
Depth 180 mm |
Height 44 mm |
Weight 1.75 kg |
